| Specification | Details |
|---|---|
| Vehicle Length | 5.99 m |
| Vehicle Width | 2.04 m |
| Vehicle Height | 2.50 m |
| Chassis Model | FAW Tiger V light truck series |
| Chassis Type | Common hazardous chemical vehicle chassis |
| Engine Brand & Model | Weichai 130 HP |
| Engine Type | Inline 4-cylinder, turbocharged, intercooler |
| Maximum Output Power | 96 kW |
| Peak Torque | 380 Nm |
| Emission Standard | EURO VI |
| Performance | Excellent power performance and fuel efficiency |
The exhaust pipe is positioned at the front, which is a typical feature of all hazardous chemical vehicles. It also comes with a fireproof cap. During exhaust emissions, sparks may inevitably be generated, which is fatal for fuel trucks, but the fireproof cap effectively prevents this issue.
The urea tank of this refueling truck is strategically positioned within the right-side protective rail, ensuring both safety and ease of access. Constructed from durable aluminum alloy, the tank features a robust cylindrical structure designed to withstand long-term use under demanding conditions. While many chassis brands typically opt for plastic-lined or plastic-coated urea tanks due to their lower production cost, this truck’s choice of a full-metal aluminum alloy tank represents a clear advantage in durability and resistance to wear. The metal construction not only offers superior resistance to physical damage and environmental factors but also extends the overall service life of the tank, reducing the likelihood of maintenance or replacement over time.
In terms of running gear, the fuel tanker truck is equipped with a Qingte axle system. Manufactured by Qingte Axle Co., Ltd., these axles are widely used in the production of specialized vehicles. Qingte is recognized for its strong technical capabilities and consistent product quality, supplying components to multiple major chassis brands. The axle system is engineered for exceptional load-bearing capacity, high stability, and reliable steering performance. These attributes are especially important for a fully loaded refueling truck, where both safety and handling precision are critical during operation.
The mounted fuel tank body is built from high-quality carbon steel, selected for its strength, corrosion resistance, and structural integrity. The tank incorporates a multi-compartment design, allowing for the safe transport of different fuel types or grades while preventing cross-contamination. Inside the tank, multiple anti-surge baffles are installed. These internal baffles play a crucial role in minimizing liquid movement during transport. Even when the tank is fully loaded, these baffles significantly reduce sloshing, which in turn enhances vehicle stability, prevents excessive body sway, and improves driver control—especially important when navigating sharp turns or uneven road conditions.
Operational efficiency is further enhanced by the well-organized superstructure layout. The discharge box is positioned inside the right-side protective rail, offering convenient access while maintaining a clean exterior profile. This discharge system is equipped with an array of functional features, including pump-in and pump-out capabilities, bottom loading for faster and safer fuel transfer, an oil-gas recovery valve to reduce emissions, an overflow prevention probe socket to avoid spillage, and an emergency shut-off device to ensure operational safety in case of unexpected incidents. Each of these elements is designed with the operator’s ease of use in mind, minimizing downtime and improving overall workflow.
On the opposite side, the left-side protective rail houses the fuel dispenser unit. This dispenser supports multiple fueling methods, allowing refueling to be carried out either by specifying a precise monetary amount or by setting a fixed quantity of fuel. This flexibility makes the vehicle suitable for a variety of operational scenarios, from industrial fleet refueling to roadside fuel delivery. Altogether, the combination of robust materials, advanced engineering, and operator-focused design ensures that this refueling truck delivers both performance and reliability in daily service.
