BRIEF
The SHACMAN L3000 24 CBM LPG bobtail tank truck, manufactured by CSCTRUCK China Tank Truck, is a highly efficient solution for transporting liquefied petroleum gas (LPG). This vehicle is built on the reliable SHACMAN L3000 chassis and features a 6×4 drive configuration, making it well-suited for various terrains and operational conditions.
The LPG tank has a capacity of 24 cubic meters (CBM), constructed from Q345R steel, a durable material known for its high strength and pressure resistance. The vehicle is powered by a robust engine offering 260 to 430 horsepower, providing ample power for heavy-duty applications. With a payload capacity of 14,910 kilograms, it ensures significant carrying efficiency for LPG distribution operations.
Designed with a focus on performance and safety, the tank truck adheres to the EURO III emission standard, balancing power and environmental compliance. It boasts a maximum driving speed of 85 km/h, enabling timely and reliable deliveries across urban and intercity routes.
The SHACMAN L3000 24 CBM LPG bobtail is engineered for reliability and efficiency, making it a preferred choice for LPG transport businesses. Its advanced features and rugged design ensure longevity and operational stability in demanding logistics environments.
FEATURES
- LPG Tank Specifications:
- Tank Volume: 24 cubic meters (CBM).
- Material: High-strength Q345R steel ensures durability and safety.
- Chassis and Drive Configuration:
- SHACMAN L3000 chassis, renowned for robustness and reliability.
- 6×4 drive type, offering excellent traction for heavy-duty operations.
- Performance:
- Engine Power: Range between 260 and 430 horsepower.
- Maximum Driving Speed: 85 km/h, balancing speed and stability.
- Payload and Efficiency:
- Payload Capacity: 14,910 kg, optimized for large-scale LPG transport.
- Meets EURO III emission standards, ensuring environmental compliance.
- Safety and Build Quality:
- The tank material (Q345R) is specifically designed for handling pressurized liquids, enhancing operational safety and longevity.
SPECIFICATION
| Item No. | Parameters |
| Cabin | One and a half row, with A/C, left-hand drive. |
| Overall Dimensions(LxWxH) | 8,700×2,500×3,690mm |
| Gross Vehicle Weight | 25,000kg |
| Curb Weight | 10,895kg |
| Payload | 14,910kg |
| Wheel Base | 4,350+1,350mm |
| Engine Brand | Cummins/WEICHAI engine |
| Engine horsepower | 260-430HP EURO III |
| Displacement | 8,300 ml(Diesel) |
| Max. Driving Speed | 85Â km/h |
| Cabin | 2~3 Passengers allowed, LHD, with an Air Conditioner. |
| Tire | 11R22.5,11pcs |
LPGÂ tank |
|
| Volume: | 24CBM 12MT |
| Tank material: | Q345R |
| Tank diameter: | 2,350mm |
| Tank thickness: | 11mm |
| Tank length: | 8,960mm |
| Filling gas | Propane(LPG) |
| Design Pressure: | 1.61Mpa |
Accessory |
|
| Safety Valve | 1 |
| Tool Box | 1 |
| Valve Box | 1 |
| Thermometer | 1 |
| Pressure Gauge | 1 |
| Emergency Valve | 1 |
| Fender | Steel |
| Fire Extinguisher | 2 |
| Anti-static Tape | 1 |
| Paint | As required |
Standard |
|
| Pressure vessels, Supervision Regulation on Safety Technology for Stationary Pressure Vessels. | |
