| Model No.: | CSCBTT015 |
| Propane Tank Volume: | 15CBM |
| Overall Dimensions(LxWxH): | 8,500×2,495×3,250mm |
| Chassis Brand: | HOWO |
| Drive Type: | 4X2 |
| Wheelbase: | 4,700mm |
| Engine Model: | YC4E160-33 |
| Engine Power: | 160 HP |
| Emission Standard: | EURO III |
| Max Driving Speed: | 95 km/h |
| Tank Material: | Q345R |
BRIEF
The 15 CBM LPG bobtail tank truck by CSCTRUCK China Tank Truck is a robust and reliable solution for transporting liquefied petroleum gas (LPG) efficiently and safely. Designed with a tank capacity of 15 cubic meters (CBM), this truck is tailored to meet the demands of bulk propane delivery.
The tank truck is built on a HOWO chassis, ensuring durability and a strong performance foundation. It features a 4×2 drive configuration, making it suitable for various terrains and operational conditions. Powering the truck is a YC4E160-33 engine, a reliable diesel engine delivering 160 horsepower (HP). This engine complies with the EURO III emission standard, reflecting a commitment to eco-friendly operations. The truck achieves a top speed of 95 km/h, ensuring timely deliveries over medium to long distances.
The LPG tank is crafted from Q345R steel, a high-strength material known for its durability and resistance to high-pressure environments, ensuring the safe containment of LPG during transportation. The material selection and tank design prioritize safety, adhering to international standards.
This LPG bobtail tank truck is engineered for operational efficiency and longevity. With advanced features and a strong emphasis on safety and environmental standards, it is an excellent choice for businesses in the energy and fuel distribution sectors. The combination of CSCTRUCK China Tank Truck’s expertise and HOWO’s engineering ensures a reliable vehicle designed to meet modern logistical demands.
FEATURES
- Tank Capacity and Material: The truck is equipped with a 15 CBM propane tank made from Q345R high-strength steel, ensuring durability and safety for transporting LPG.
- Chassis and Drive: Built on a HOWO chassis with a 4×2 drive configuration, providing stability and reliable performance.
- Engine Specifications: Powered by a YC4E160-33 engine model with 160 HP output, compliant with EURO III emission standards for reduced environmental impact.
- Performance: Capable of reaching a maximum driving speed of 95 km/h, suitable for both urban and highway transportation.
- Design and Safety: Specifically designed for LPG transport, the truck incorporates advanced safety systems and efficient load distribution.
SPECIFICATION
| Item No. | Parameters |
| Overall Dimensions(LxWxH) | 8,500×2,495×3,250mm |
| Driving Model | Right-hand drive |
| Gross Vehicle Weight | 15,795 kg |
| Curb Weight | 9,940kg |
| Payload | 5,660 kg |
| Wheel Base | 4,700 mm |
| Front/rear Tread | 1,886/1,845 mm |
| Approach/Departure Angle | 27/20Â degree |
| Engine | Yuchai 4110, YC4E160-33 |
| Engine horsepower | 160 HP, EURO III |
| Displacement | 4,260ml(Diesel) |
| Max Driving Speed | 95Â km/h |
| Cabin | 2~3 Passenger allowed, with A/C |
| Tire | 9R20(6 pc with 1 spare) |
| LPG tank | |
| Volume: | 15 CBM |
| Tank material: | Q345R |
| Tank diameter: | 2,000mm |
| Tank thickness: | 10mm |
| End plate | 10mm |
| Tank length: | 5,140mm |
| Gas phase | DN50 |
| Liquid Phase | DN50 |
| Filling gas | Propane(LPG) |
| Design Pressure: | 1.61Mpa |
| Accessory | |
| Level Gauge | Manual rotation type, at the rear of the tank. |
| Safety Valve | 1, DN80 |
| Tool and Valve Box | 1 |
| Thermometer | 1 |
| Pressure Gauge | 1 |
| Emergency Valve | 1 |
| Fender | Steel |
| Fire Extinguisher | 2 |
| Exhaust shaft | At the front of the truck for safety. |
| Tank Mounted on Chassis Brand |
|---|
