Mobile Refueling Truck Specifications
1️⃣ Chassis Configuration
| Item | Details |
|---|---|
| Cab | Dongfeng Dolica |
| Wheelbase | 2,700 mm |
| Engine | Quanchai, 130 HP |
| Gearbox | Wanliyang 5-speed |
| Tires | 6.50R16LT 10PR steel radial |
| Safety & Braking | ABS, speed limiter, front disc brakes, air brake cut-off, exhaust brake |
| Comfort | Air conditioning |
| Emergency/Safety | Run-flat tire emergency device, front collision warning, lane departure warning |
2️⃣ Body Configuration
| Item | Details |
|---|---|
| Tank Volume | Official: 2.2 m³; Effective: 2.5 m³ |
| Certification | Fuel tank inspection report (gasoline/diesel) |
| Material | Q235B steel plate |
| Tank Thickness | Cylinder: 4.2 mm; End cap: 4.5 mm; Baffle: 4.2 mm |
| Compartments | Single compartment |
| Manhole | One manhole on the tank top |
| System | EU-standard: Bottom loading, vapor recovery, anti-overflow probe, anti-static hose reel |
| Valves & Pumps | One bottom valve with voice alarm; 60/30 fuel pump (in/out) |
| Options | High-flow fuel dispenser; 15 m reinforced hose reel with nozzle |
| Accessories | Rear ladder, manual guardrail, toolbox, rear bumper, side protection rail |
| Standards | Built to new safety/environmental standards |
| Documentation | Gasoline/diesel test report, chassis certificate, vehicle certificate. |
Summary for Export
This EURO VI Dongfeng Dolica 3CBM mobile refueling truck is built on a Dongfeng Dolica chassis with a 2,700 mm wheelbase and powered by a 130 HP Quanchai engine. It features a 5-speed Wanliyang gearbox, ABS, speed limiter, front disc brakes, air brake cut-off, exhaust brake, and safety systems including collision and lane departure warnings, plus an emergency run-flat device.
The tank body has an official capacity of 2.2 m³ and an effective capacity of 2.5 m³, made of Q235B steel with a cylinder thickness of 4.2 mm and an end cap thickness of 4.5 mm. It supports gasoline/diesel transport, EU-standard loading and safety systems, a 60/30 dedicated fuel pump, optional high-flow dispensers, and includes a rear ladder, guardrails, toolbox, and side/rear protections. All tanks come with inspection reports, and the vehicle is supplied with a complete chassis.
