Safety:
The Dayun oil refueling truck features a specially designed integrated manhole cover on the tank body, which is corrosion-resistant and has emergency venting capabilities. It includes a built-in breathing valve that effectively regulates internal tank pressure to prevent fuel leakage, significantly improving safety during fuel transport. The vehicle body is designed based on the latest European safety frame structure concept, complying with EEC regulations for frontal, side, and rollover impact resistance. The cab is built with advanced high-strength materials and features a full-floating anti-collision design. It uses an energy-absorbing, collapsible steering column system, providing a high level of safety.
Reliability:
The fuel tank is manufactured using an imported original-end flanging machine. All end caps undergo cold treatment for easy alignment and excellent quality. The end caps are welded using automated mechanical welding for consistent weld quality. The anti-surge baffles are formed in a single stamping process, capable of withstanding high impact forces, thereby increasing the overall tank strength and extending its service life. Key components such as valves and connectors are made from stainless steel or aluminum alloy, ensuring excellent sealing and high reliability.
Efficiency:
The Dayun oil refueling truck is equipped with a vapor recovery system that effectively reduces fuel vapor emissions, making it energy-saving, environmentally friendly, and highly efficient. It also enhances safety during vehicle operation.
| Specification | Details |
|---|---|
| Engine | Yunnan YN, 130 horsepower |
| Transmission | Wanliyang 6-speed manual |
| Tires | 7.50R16 steel-belted radial tires |
| Braking System | Front disc, rear drum brakes with ABS |
| Chassis | Solid and stable |
| Steering | Power steering |
| Standard Features | Electric windows, central locking, factory-installed air conditioning, ABS, air brake system |
| Operation | Simple and convenient |
The upper tank can be built to a 6-cubic-meter capacity, and materials can be selected according to user requirements: stainless steel, aluminum alloy, or regular carbon steel. The price of the fuel truck varies based on the material used. It also comes with comprehensive safety equipment as standard, including a full set of European standard fittings, anti-overflow probes, bottom valves, fire extinguishers, and more.
