Chassis | |
Size | 11,800 x 2,490 x 3,690 mm |
GVW/Curb Weight | 31,000/14,910 kg |
Wheelbase | 1,800+4,600+1,350 mm |
Tire | 12.00R20, 10+1 tires |
Engine | |
Type | Diesel |
Make/Model | WEICHAI/WP10.400E22/400hp/Euro 2 |
BRIEF:
The HOWO 15-Ton LPG Bobtail Truck is a heavy-duty and high-capacity solution meticulously designed for the secure and efficient transportation of LPG (Liquid Petroleum Gas). This robust vehicle consists of a reliable HOWO truck chassis, a specially engineered LPG tank, a dependable LPG vane pump, and a comprehensive PLG filling system. The filling system is equipped with essential features such as a flow meter, temperature meter, a 15-meter filling hose, and a filling gun. The truck is engineered for the safe transportation of LPG in its liquid gas state, specifically when it contains a mixture of butane and propane, with the weight of propane capped at a maximum of 30%. Moreover, it offers an optional electronic scale for precise LPG deliveries.
This propane tank truck is a robust and high-capacity solution for the safe and efficient transportation of LPG. It provides the necessary features and an optional electronic scale for precise and accountable LPG delivery services. This vehicle is ideal for businesses involved in the secure and reliable transportation of LPG.
FEATURES:
- Powerful Chassis: The HOWO truck chassis is equipped with a robust 400hp engine that complies with Euro 2 emission standards. It features a 10-speed manual transmission and is fitted with 12.00R20 tires, providing excellent stability and durability for demanding transportation tasks over varying terrains.
- Reliable Vane Pump: The truck is equipped with the dependable USA Corken vane pump, specifically the Z2000 model. This vane pump ensures the efficient and reliable handling of LPG during transportation.
- High Capacity LPG Tank: The LPG tank is designed for high-capacity operations, with a voluminous 35,000-liter capacity. It is constructed from durable Q345R material with a 10mm thickness and has a remarkable loading capacity of 15 tons, making it suitable for safe and reliable LPG transportation.
- Standard Gauges: The vehicle is equipped with essential pressure and temperature meters, along with a liquid gauge, to enhance safety and control during LPG delivery operations.
- Optional Electronic Scale: For precise and accountable LPG deliveries, an optional electronic scale is available. This feature allows users to accurately measure and verify the quantity of gas being delivered.
SPECIFICATIONS:
Category | Specifications |
---|---|
Chassis | |
Size | 11,800 x 2,490 x 3,690 mm |
GVW/Curb Weight | 31,000/14,910 kg |
Wheelbase | 1,800+4,600+1,350 mm |
Tire | 12.00R20, 10+1 tires |
Engine | |
Type | Diesel |
Make/Model | WEICHAI/WP10.400E22/400hp/Euro 2 |
Transmission | |
Model | SINOTRUK/HW19710 |
Gears | 10F+2R |
Operation | Manual |
Cabin | |
Driving | HOWO, 8×4, LHD/RHD |
Type | Seats, radio, MP3 |
Passenger No. | 2 seats & 1 sleeper |
LPG TANK | |
Filling Medium | LPG |
Capacity | 15 tons/35,000 Liters |
Working Temperature | -40 ~ 50°C |
Tank Material | Q345 |
Tank Diameter | 2,350 mm |
Tank Thickness | 12 mm |
End Plate Thickness | 12 mm |
Tank Length | 8,960 mm |
Gas Phase | Flange Type, DN50, other sizes optional |
Liquid Phase | Flange Type, DN80, other sizes optional |
Working Pressure | 1.61 Mpa |
Design Pressure | 1.71 Mpa |
Testing Pressure | 2.21 Mpa |
Corrosion Allowances | 1.0 mm |
