Model No.: | CSCFTT010 |
Fuel Tank Truck: | 10,000 liters, 1 compartment |
Overall Dimension(mm)(LxWxH): | Approx.7,900×2,500×2,650mm |
Chassis Brand: | HOWO |
Drive Type: | 4×2 |
Wheelbase(mm): | 4,500 |
Max.Payload(kg): | 10,000 |
Curb weight(kg): | 5,500 |
Engine Model: | YC4E160-33(160HP) |
Rated Power Rev(kW/rpm): | 118kW/2,600rpm |
Emission standard: | EURO 2 |
Tanker material: | Q235, carbon steel |
Pump Model: | 80YHCB-60 |
Flow: | 60m3/h |
Pressure: | 0.6Mpa |
Rotate Speed: | 970r/min |
Categories: Carbon Steel Tank Truck, Fuel Tank Truck
Description
BRIEF
The HOWO 10,000-liter fuel tank truck, produced by CSCTRUCK China Tank Truck, is a robust and efficient vehicle for fuel transportation. Built on a HOWO chassis with a 4×2 drive type, it offers a maximum payload of 10,000 kg, making it suitable for medium-scale fuel distribution tasks. The fuel tank is constructed from durable Q235 carbon steel and features a single compartment with a total capacity of 10,000 liters, ensuring secure and safe fuel transport.
This truck is powered by the YC4E160-33 engine model, which provides 160 horsepower (118kW) at 2,600 rpm. Meeting the EURO 2 emission standard, it balances performance with environmentally-conscious design. The engine’s specifications make it a reliable option for various operational conditions, combining sufficient power with reasonable fuel efficiency.
Fuel distribution is managed by an 80YHCB-60 pump, which has a flow rate of 60 cubic meters per hour and operates at 0.6 MPa pressure with a rotation speed of 970 revolutions per minute (rpm). This allows for efficient and fast fuel transfer during operations.
Overall, the HOWO 10,000-liter fuel tank truck by CSCTRUCK China Tank Truck is a reliable and powerful solution for fuel transportation. It offers a balance of durability, performance, and operational efficiency. It is particularly suited for businesses needing a reliable medium-duty fuel transport solution.
FEATURES
1. Fuel Tank Capacity and Build: The truck has a 10,000-liter fuel tank with one compartment, made from Q235 carbon steel, ensuring durability and resistance to corrosion.
2. Chassis and Drive Type: The truck is built on a HOWO chassis with a 4×2 drive configuration, offering good handling and stability on standard roads.
3. Engine and Power: Powered by a YC4E160-33 engine, the truck produces 160HP (118kW) at 2,600 rpm, meeting the EURO 2 emission standards for moderate fuel efficiency and lower emissions.
4. Pump System: Equipped with an 80YHCB-60 pump model, the truck supports a flow rate of 60 m³/h with a pressure of 0.6 MPa and a rotation speed of 970 r/min, allowing efficient fuel transfer.
5. Payload Capacity: The truck has a maximum payload capacity of 10,000 kg, which makes it suitable for transporting large quantities of fuel over long distances.
SPECIFICATION
Main Specification |
|
Product Name | HOWO 10000 Liters Fuel Tank Truck |
Truck model | CSCFTT010 |
Driving Type |  4×2, Left/right hand drive |
Weights | |
Max.Payload (kg) | 10,000 |
Curb weight(kg) | 5,500 |
Dimensions | |
Wheelbase (mm) | 4,500 |
Overall Dimension (mm) | Approx.7,900×2,500×2,650 |
Box dimension | 10,000 liters |
Engine | |
 Engine Model | YC4E160 -33(160HP) |
Engine type | 4 stroke water-cooled, Inter-cooling, Turbocharged |
Displacement (L) | 4.257L |
Rated power Rev ((Kw/rpm) | 118kw/2,600rpm |
Max Torque (N*m)/Rev (rpm) | 600N.m/1,200-1,600rpm |
Emission standard | EURO 2 |
 Drive Line | |
Transmission | DC6J65TC, 6 forwards, 1 reverse gear, manual operation |
Steering | With power steering |
Brake system | Air brake |
Cab | |
Cab | one and half row, Howo cabin, A/C optional |
Axles | |
Front axle | 3.2 tons |
Rear axle | 8 tons |
Tire specification | |
Tire specification | 8.25R20 standard tire,6 tires+1 spare tire |
Specification of Fuel truck | |
Tank capacity | 10,000 liters, 1 compartment |
Tanker material | Q235, carbon steel |
Manhole | 1 pcs manhole fixed on top of tank |
Outlet and inlet | 1 pcs outlet and 1 pcs inlet |
Oil rope | 2 pcs oil rope |
Fire extinguisher | 2 pcs 4kg fire extinguisher |
Anti-static devices | Including ground towing, static line plate |
Pump | Equipped Oil pump (driven from gearbox by PTO) |
Model: 80YHCB-60 | |
Flow: 60m3/h | |
Pressure: 0.6Mpa | |
Rotate Speed: 970r/min | |
Fuel dispenser | This dispenser can use for diesel and gasoline |
