BRIEF
The Foton 12 Wheelers 40 CBM Feed Bulk Truck produced by CSCTRUCK China Tank Truck is a highly efficient and reliable solution designed for the modern livestock and feed transportation industry. Built on the durable Foton BJ1310FE chassis, this heavy-duty bulk feed truck combines large carrying capacity, advanced unloading technology, and economical operation, making it ideal for feed mills, poultry farms, pig farms, and large-scale breeding operations.
Equipped with a massive 40m³ bulk feed tank, the Foton 12 Wheelers 40 CBM Feed Bulk Truck is capable of transporting large quantities of animal feed efficiently while maintaining feed quality during transportation. The tanker body measures 9,000 × 2,550 × 2,620 mm, offering sufficient storage space for different feed materials. The tank can also be divided into 2 to 4 independent compartments, allowing simultaneous transportation of multiple types of feed without cross-contamination.
Powered by the reliable Foton Cummins ISGe5-360 diesel engine, the vehicle delivers 265kW of power from an 8.9L displacement engine, ensuring strong performance and stable operation even under full load conditions. With a gross vehicle weight of 31,000kg and a maximum speed of 89km/h, the truck offers excellent road adaptability and transportation efficiency for long-distance delivery.
The truck adopts an advanced screw auger unloading system, which can be powered either by external three-phase electricity or by the onboard generator driven through the PTO system. This flexible design allows the truck to operate efficiently in areas with or without an industrial power supply.
Compared with traditional bagged feed transportation, the bulk feed truck significantly reduces labor intensity, packaging costs, and feed loss. Its sealed tank structure effectively prevents feed contamination, ensuring hygienic and high-quality feed delivery. With easy maintenance, convenient operation, and continuous working capability, the Foton 12 Wheelers 40 CBM Feed Bulk Truck is an ideal choice for modern agricultural logistics and bulk feed transportation applications.
FEATURES
- Large 40m³ Bulk Feed Capacity
The truck is equipped with a spacious 40 cubic meter feed tank, enabling efficient transportation of large volumes of animal feed for poultry farms, pig farms, and feed production enterprises, reducing delivery frequency and improving logistics efficiency. - Multi-Compartment Tank Design
The tanker can be divided into 2 to 4 independent compartments, allowing the transportation of different types of feed simultaneously while preventing cross-contamination and maintaining feed quality. - Powerful Foton Cummins Engine
Powered by the reliable Foton Cummins ISGe5-360 diesel engine with 265kW output and 8.9L displacement, the truck delivers strong driving performance, excellent load-carrying capability, and stable operation for long-distance transportation. - Flexible Screw Auger Unloading System
The advanced screw auger unloading system supports both external 3-phase electric power and onboard PTO-driven generator operation, ensuring efficient unloading performance even in remote areas without industrial electricity. - Economical and Hygienic Feed Transportation
Compared with traditional bagged feed transport, the sealed bulk feed tank reduces labor costs, packaging expenses, and feed loss while effectively protecting feed from contamination, ensuring safe, clean, and high-quality delivery.
SPECIFICATION
| Truck brand | CSCTRUCK China Tank Truck | Truck model | Bulk feed truck |
| Gross weight | 31,000kg | Tanker volume | 40m³ |
| Rated weight | 15,800kg | Overall dimensions(LxWxH) | 12,000×2,550×3,950mm |
| Curb weight | 15,060kg | Body dimension | × × |
| Cabin seat | 3 | ||
| A/D angle | 13/12 | F/R overhang | 1,480/2,575mm |
| Axles | 3 | Wheel base | 1,995+4,400+1,350mm |
| Axles loading | 6,500/6,500/1,800kg | Max speed | 89km/h |
| Tanker Dimension(LxWxH) | 9,000×2,550×2,620(length ×width×height )(mm). | ||
| Chassis model | BJ1310FE | ||
| Brand Name | Foton | Manufacturer | BAIC Foton Motor Co., Ltd |
| Overall dimension(LxWxH) | 12,000×2,550×3,950 | Tyre quantity | 12+1Spare |
| A/D angle | 13/12 | Tyre size | 11.00R20 18PR |
| Leaf spring quantity | 9/9/10 | Front track | 2,010/2,010mm |
| Fuel type | Diesel | Rear track | 1,860/1,860mm |
| Standard | Euro III | ||
| Engine model | Manufacturer | Displacement | Power |
| ISGe5-360 | Foton Cummins Engine Co., Ltd | 8,900ml | 265kW |
| Equipment | 1. 40m³ Bulk Feed Truck adopt truck chassis, suitable for different breeding farms and feedmills. 2. Adopt a screw auger to discharge, use three-phase power or power from a generator driven by a truck, so that it can satisfy customers with or without three-phase power at the work site. 3. The tank can be divided into 2 to 4 compartments for different kinds of feed. With a simple structure, it is easy to control and maintain. 4. Use PTO and a generator to make electrical power, offering optimal performance and price ratio. Loading and unloading by itself don’t need to connect to the Industrial electric power. |
||
| Advantages | – Successfully saving feed packing cost and labor cost compared with bagged feed transportation. – Easy to supply feed at a certain time and a certain place, convenient to manage. Continuous operation increases work efficiency. – Deliver feed in a hermetic tank, which can avoid feed pollution, assure feed quality, and reduce feed loss. |
||
