Model No.: | CSCMTT040 |
Milk Tank Volume: | 40,000kg |
Overall Dimensions(LxWxH): | 12,600×2,500×3,900mm |
Milk Tank material: | Food grade stainless steel 304-2B |
Shape: | Oblong type |
Loading quality(kg): | 40,000 |
Curb weight(kg): | 11,000 |
Tank thickness: | 4mm |
Axle: | Fuhua 13-ton bridge |
Wheelbase(mm): | 6,850+1,310+1,310 |
Breathing valve: | 2 sets |
Discharge valve: | 1/DN50 |
Categories: Milk Tank Truck, Stainless Steel Tank Truck
Description
BRIEF
The 40-ton payload milk tank semi-trailer produced by CSCTRUCK China Tank Truck is a robust and specialized vehicle designed for efficient and hygienic transportation of large volumes of milk. With a 40,000 kg loading capacity, this semi-trailer is built to handle high-demand deliveries. The tank is made from food-grade stainless steel 304-2B, ensuring that the milk remains uncontaminated during transit. The steel has a 4mm thickness, providing durability and corrosion resistance, while the oblong shape of the tank maximizes space and ensures stability during movement.
Weighing 11,000 kg when empty, the semi-trailer is equipped with a Fuhua 13-ton bridge axle, contributing to its sturdy construction and ability to carry heavy loads safely over long distances. The tank is fitted with 2 breathing valves to maintain the internal pressure, ensuring the milk remains fresh and unspoiled by external factors like air contamination or pressure changes. A DN50 discharge valve allows for easy and controlled unloading of milk.
This semi-trailer is built to adhere to strict food safety and hygiene standards, making it a reliable option for large-scale dairy transport. With high-quality materials and components, this 40-ton payload milk tank semi-trailer combines efficiency, safety, and durability, meeting the needs of the modern dairy industry.
FEATURES
1. High Payload Capacity: The trailer has a loading capacity of 40,000kg, making it suitable for transporting large volumes of milk.
2. Food-Grade Stainless Steel Tank: The milk tank is made of stainless steel 304-2B, ensuring compliance with food safety standards and corrosion resistance.
3. Sturdy Construction: The tank features a 4mm thick stainless steel wall, providing durability and resistance to wear during transport.
4. Efficient Valve System: Equipped with 2 sets of breathing valves and a DN50 discharge valve, ensuring safe pressure management and smooth discharge of milk.
5. Heavy-Duty Axles: The trailer includes Fuhua 13-ton bridge axles, offering strong support for the load and enhancing stability during transport.
SPECIFICATION
Item |
Specification |
|
Tank material | Food grade stainless steel 304-2B | |
Beam material | Carbon steel Q235 | |
shape | Oblong type | |
Loading quality(kg) | 40,000 | |
curb weight(kg) | 11,000 | |
total mass(kg) | 51,000 | |
Head thickness | 5mm | |
Tank thickness | 4mm | |
Thickness of sub-bin board | 4mm | |
traction pin | 90# | |
front/rear suspension(mm) | Front:-,rear:1630 | |
departure angle | Front:-, rear:12 | |
suspension | Leaf spring-/8/8/8 | |
leaf spring | Front 8, Middle 8, Back 8 | |
axle | Fuhua 13-ton bridge | |
Wheelbase(mm) | 6,850+1,310+1,310 | |
Number of tires | 12 | |
Overall Dimensions(LxWxH): | 12,600×2,500×3,900mm | |
Tire | 12R22.5 12PR(13 including spare tire) | |
manhole | 2 | |
breathing valve | 2 sets | |
Discharge valve | 1/DN50 |
