Model No.: | CSCMTST038 |
Milk Tank Volume: | 38 CBM |
Overall Dimensions(LxWxH): | 10,200×2,530×3,800mm |
Max Payload: | 32,000KG |
Axle: | 13/16 Ton Fuwa/BPW/CIMC |
Landing Gear: | JOST/FUWA/Yahua Brand 28T |
King Pin: | 2″(50mm)or3.5″(90mm) JOST |
Leaf Spring: | 90(W)mm x 13(Thickness)mm x 10(Layer) |
Material: | Stainless steel |
Categories: Milk Tank Truck, Stainless Steel Tank Truck
Description
BRIEF
The 38 CBM milk transport semi-trailer by CSCTRUCK China Tank Truck, a Chinese tank truck manufacturer, is designed to handle large-scale milk transportation. With a total capacity of 38 cubic meters (CBM), the tank is constructed from stainless steel, ensuring hygienic and corrosion-resistant conditions for transporting liquid dairy products. The trailer can support a maximum payload of 32,000kg, making it ideal for heavy-duty operations over long distances.
Key components of the trailer include axles from Fuwa, BPW, or CIMC, rated at either 13 or 16 tons depending on the configuration, offering durability and reliable load support. The landing gear comes from JOST, FUWA, or Yahua, rated at 28 tons, ensuring stable and secure parking during loading and unloading. The trailer is equipped with either a 2-inch (50mm) or 3.5-inch (90mm) JOST kingpin, which connects the trailer to the tractor, providing flexibility for different types of trucks.
The suspension system includes leaf springs measuring 90 mm in width, 13 mm in thickness, and 10 layers, contributing to a robust suspension that can handle rough terrains while minimizing the impact on the milk being transported. The combination of high-quality materials, heavy-duty components, and thoughtful design ensures that the 38 CBM milk transport semi-trailer delivers reliability and efficiency for the dairy industry.
FEATURES
1. 38 CBM Stainless Steel Milk Tank – The milk tank is made of stainless steel, ensuring hygienic conditions for milk transportation and providing excellent durability and corrosion resistance.
2. Max Payload Capacity of 32,000 KG – The trailer is designed to handle a maximum load of up to 32,000 kg, making it suitable for large-scale milk transportation.
3. 13/16 Ton Fuwa/BPW/CIMC Axle – The trailer is equipped with high-strength axles from reputable brands like Fuwa, BPW, or CIMC, providing robust support for heavy loads.
4. JOST/FUWA/Yahua 28T Landing Gear – Featuring landing gear from JOST, FUWA, or Yahua, with a 28-ton capacity for stable and secure parking and support when detached from the truck.
5. 2″(50mm) or 3.5″(90mm) JOST King Pin and Heavy-duty Leaf Spring – The kingpin is available in 2 sizes (2″ or 3.5″) to fit various truck couplings, and the trailer uses a strong leaf spring suspension system (90mm width, 13mm thickness, 10-layer) for load stability.
SPECIFICATION
Item |
Value |
Use
|
Milk Transport
|
Type
|
Semi-Trailer
|
Material
|
T700/Q345
|
Size
|
10,200×2,530×3,800mm
|
Max Payload
|
32,000KG
|
Place of Origin
|
China
|
Hubei
|
|
Brand Name
|
CSCTRUCK China Tank Truck |
Axle
|
13/16 Ton Fuwa/BPW/CIMC
|
Suspension
|
Mechanical Suspension Air Suspension
|
Tire
|
10.00R20/ 11.00R20/ 12R22.5
|
Landing Gear
|
JOST/FUWA/Yahua Brand 28T
|
Kingpin
|
2″(50mm) or 3.5″(90mm) JOST
|
Brake System
|
WABCO
|
Leaf Spring
|
90(W)mm * 13(Thickness)mm * 10(Layer)
|
Milk Tank Volume:
|
38CBM
|
The dead weight of the vehicle
|
8,000KG
|
Material
|
Stainless steel
|
