Model No.: | CSCDFB010 |
Fuel Tank Volume: | 10 CBM |
Overall Dimensions(LxWxH): | 6,995×2,500×3,200mm |
Chassis Brand: | ISUZU FTR |
Drive Type: | 4X2 |
Wheelbase: | 3,800mm |
Max. Driving Speed: | 90km/h |
Payload: | 7,500kg |
Engine Model: | CY4102 |
Engine Power: | 120HP |
Emission Standard: | Euro II |
Fuel Tank Material: | Carbon steel |
BRIEF
The ISUZU FTR 10 CBM diesel fuel bowser, manufactured by CSCTRUCK China Tank Truck, is a robust and efficient solution for fuel transportation. Built on the reliable ISUZU FTR chassis, this tank truck combines durability, performance, and practicality to meet the needs of industries requiring bulk fuel delivery.
Key features include a 10 cubic meter (CBM) carbon steel fuel tank, providing ample capacity for transporting diesel or other liquid fuels. The truck operates on a 4×2 drive type, offering a balance of maneuverability and traction for urban and highway use. It is powered by the CY4102 engine, delivering 120 horsepower under a Euro II emission standard, ensuring compliance with environmental regulations while maintaining efficiency.
The bowser’s design supports a maximum payload of 7,500 kg, making it suitable for medium-scale fuel distribution. With a top driving speed of 90 km/h, the vehicle facilitates timely deliveries without compromising safety. The tank itself is constructed from durable carbon steel, providing excellent resistance to wear and ensuring the safe containment of fuel during transport.
This ISUZU FTR fuel bowser is engineered for reliability and ease of operation. Its robust chassis and efficient engine make it ideal for businesses in the energy, construction, and logistics sectors, where the transportation of fuel is critical. CSCTRUCK China Tank Truck, a trusted name in specialized vehicle manufacturing, ensures that this vehicle meets high standards of quality and performance, making it a valuable asset for fuel distribution operations.
In summary, the ISUZU FTR 10 CBM fuel bowser is a dependable, mid-range fuel vehicle designed to deliver efficiency and reliability in demanding operational environments.
FEATURES
- Fuel Tank Capacity: Equipped with a 10 CBM (10,000 liters) carbon steel fuel tank for efficient transportation and storage of diesel fuel.
- Chassis and Drivetrain: Built on the ISUZU FTR chassis with a 4×2 drive type, ensuring reliable performance and durability for fuel delivery operations.
- Engine Specifications: Powered by the CY4102 engine, delivering 120HP with a Euro II emission standard, providing a balance of power and environmental compliance.
- Payload and Speed: Capable of carrying a 7,500 kg payload and achieving a maximum driving speed of 90 km/h, suitable for medium-range fuel distribution.
- Construction and Design: The carbon steel fuel tank offers robust construction for safety and longevity, meeting industrial standards for fuel transport.
SPECIFICATION
Chassis | |||
Vehicle Model | ISUZU FTR 10 CBM Diesel Fuel Bowser | ||
Chassis brand | ISUZU FTR | ||
Driving model | Left or Right-hand drive | ||
Overall dimensions(LxWxH) | mm | 6,995×2,500×3,200(mm) | |
Cube Weight | kg | 4,150 | |
Payload | 7,500 | ||
Wheelbase | mm | 3,800 | |
Exhaust/hp | ml/ps | 3,225/88 | |
Max speed | km/h | 90 | |
Tire specification | 7.50R16 | Engine type | CY4102, 120hp |
Traction system | 4×2 | Transmission | 6-speed with overdrive |
Number of axles | 2 | Axle Load(kg) | 2,400/7,200 |
Engine | Chaochai, diesel, 6-cylinder in-line with water cooling. | ||
Tank Body | |||
Shape | Monoblock Cylinder | ||
Total Volume(m3) | 10 CBM | ||
Tanker Body Material | 5mm carbon steel | ||
End plate | 5mm carbon steel | ||
Manhole cover | Aluminum manhole cover, ∮500mm, 1 set with 1 breather valve | ||
Bottom Valve | 1 set | ||
Discharging valve | 1 set ∮80mm discharging valve | ||
Tire | 7.50R16 with 1 spare tire, a total of 7 pieces | ||
Painting | Complete Chassis sand blasting to clean rust, 1Â coat of anti-corrosive prime, 2Â coats of final paint | ||
Fire Distinguish | 2 sets | ||
Accessories | One standard toolbox. |
Tank Mounted on Chassis Brand |
---|
