Model No.: | HOWO 20 CBM Chemical Tank Truck |
Chemical Tank Volume: | 20 CBM |
Overall Dimensions(LxWxH): | 9,600×2,500×3,300mm |
Chassis Brand: | HOWO |
Drive Type: | 6×4 |
Wheelbase: | 4,300+1,350mm |
Engine Model: | WD615.69 |
Engine Power: | 336HP |
Emission standard: | EURO 3 |
Tanker Body Material: | 5mm Carbon steel |
Categories: Carbon Steel Tank Truck, Chemical Tank Truck
Description
BRIEF
The HOWO 20 CBM Chemical Tank Truck, manufactured by CSCTRUCK China Tank Truck, is a robust and efficient vehicle designed for the safe transportation of chemicals. This tanker truck boasts a substantial capacity of 20 cubic meters, making it suitable for significant loads. The truck is built on a reliable HOWO chassis, which is known for its durability and performance.
The vehicle features a 6×4 drive type, providing excellent traction and stability, essential for navigating various terrains and ensuring safe transport of hazardous materials. Under the hood, the Chemical Tank Truck is powered by the WD615.69 engine model, delivering a powerful 336 horsepower. This engine meets the EURO 3 emission standards, reflecting a balance between performance and environmental considerations.
The tanker body of the truck is constructed from 5mm carbon steel, ensuring high durability and resistance to the corrosive nature of many chemicals. This robust construction is critical for maintaining the integrity of the cargo and ensuring the safety of both the vehicle and its surroundings.
Overall, the HOWO 20 CBM Chemical Tank Truck is a reliable and efficient solution for the transportation of chemicals, offering a blend of power, capacity, and safety features. Its design and build cater to the demanding requirements of chemical transport, making it a valuable asset for companies in the logistics and chemical industries.
FEATURES
1. Large Capacity Tanker:
  – The truck is equipped with a 20 CBM (cubic meter) chemical tanker, making it suitable for transporting a substantial volume of chemicals, ensuring efficiency in operations involving large quantities.
2. Durable Tanker Body:
  – The tanker body is constructed from 5mm carbon steel, providing durability and resistance to corrosion, which is essential for safely transporting various chemicals.
3. Powerful Engine:
  – It features the WD615.69 engine model, which delivers 336 horsepower. This powerful engine ensures reliable performance and the capability to handle heavy loads and long-distance transportation.
4. Emission Standards:
  – The truck complies with the EURO 3 emission standard, reflecting a balance between performance and environmental responsibility by reducing harmful emissions compared to older standards.
5. Reliable Chassis and Drive:
  – Built on the HOWO chassis with a 6×4 drive type, the truck offers stability and reliability, essential for handling challenging road conditions and ensuring the safe delivery of chemical products.
SPECIFICATION
Vehicle Description |
||
Overall dimensions(LxWxH) | 9,600*2,500*3,300mm | |
GVW | 25,000kg | |
Curb weight | 10,910kg | |
Chassis brand | SINOTRUK HOWO | |
Traction type | 6×4, left/right hand drive | |
Chassis Description |
||
Chassis model | HOWO 20 CBM Chemical Tank Truck | |
Cab | HW76 cabin, flat roof with 1 sleeper, A/C, ABS | |
Wheelbase | 4,300+1,350mm | |
Tire specification | 12R22.5 | |
Tire quantity | 10+1 units | |
Engine | Engine model | WD615.69 |
Emission level | Euro 3 (EGR) | |
Displacement/output | 9,726ml/247kw | |
Horsepower | 336HP | |
Gearbox | Model | HW19710 |
Number of gears | 10 forward gears& 2 reverse | |
Brake system | Type | Drum |
Service brake | Dual circuit compressed air brake | |
Park brake | Power spring brake acting on the rear wheel | |
Auxiliary brake | WEVB | |
Axle | Front | HF-7T |
Rear | ST-16T | |
Suspension | Front | Semi-elliptic leaf spring |
Rear | Trapezoidal leaf spring | |
Fuel tanker | Type | Steel fuel tanker |
Capacity | 400L | |
Up-parts Description |
||
Tanker | Capacity | 20 CBM |
Material | Carbon steel | |
Thickness | 5mm | |
Standard equipment | Equipped with 4 sets of manholes. Equipped with a double discharge valve and valve box. Equipped with surge baffles, ladder, roof coaming, skid-resistant walkway, and toolbox. Equipped with electrostatic conducting tape and double fire extinguishers. |
