BRIEF
The 60-ton payload fuel tank semi-trailer, produced by CSCTRUCK China Tank Truck, is a robust and efficient transport solution designed for fuel distribution. With a rated load capacity of 60,000 kg, this trailer is equipped with 3 axles and an aluminum alloy fuel tank, ensuring both lightweight and corrosion resistance. The aluminum alloy construction also enhances fuel efficiency and increases payload capacity due to its lower weight compared to steel.
This fuel tank semi-trailer offers versatility with either mechanical or air suspension systems, catering to different road conditions and preferences for ride comfort and stability. It features a standard 28-ton landing leg, providing strong support during loading and unloading. Additionally, the trailer is outfitted with a 2″ (50mm) or 3.5″ (90mm) JOST kingpin, allowing compatibility with a range of tractor units.
For safety and efficient fuel handling, the trailer includes an aluminum alloy subsea valve, which is durable and lightweight. The electrical system is powered by a 24V, 7-core socket, ensuring a reliable connection to the tractor’s power supply for lighting and signal functions.
This 60-ton fuel tank semi-trailer is built for high performance, safety, and long service life, making it an ideal choice for large-scale fuel transportation across diverse terrains.
FEATURES
1. High Payload Capacity: The trailer has a rated load capacity of 60,000 kg (60 tons), making it suitable for transporting large volumes of fuel.
2. Durable Aluminum Alloy Fuel Tank: The fuel tank is made from aluminum alloy, which offers a lightweight structure while providing high resistance to corrosion and ensuring fuel safety.
3. Suspension Options: It comes with either a mechanical suspension or an air suspension option, offering flexibility for different road conditions and operational needs.
4. JOST King Pin and Landing Leg: Equipped with a 2″ (50mm) or 3.5″ (90mm) JOST King Pin and a standard 28-ton landing leg, ensuring stable and secure coupling and uncoupling during operations.
5. Advanced Electrical System: The trailer is fitted with a 24V, 7-core socket electrical system, providing power for essential trailer lighting and safety systems during operation.
SPECIFICATION
Fuel Tank Semi Trailer |
||||
| Dimension(Optional) |
Axle No. |
Rated Load (kg) |
Tire No. |
Tire Size |
|
By Customer Needs |
2 |
40,000 |
8 |
825R20 10.00R20 11.00R20 12.00R20 12R22.5 (Other Size Tire Contact us) |
| 3 |
60,000 |
12 | ||
| 4 | 80,000 | 16 | ||
|
other |
other |
other | ||
| Tank material |
Aluminum alloy |
5182 |
||
| Thickness | 5.5mm | |||
| Anti-wave plate |
6mm |
|||
|
Head |
Aluminum alloy thickness 7mm |
|||
| Tank Top Walkway |
Carbon steel, anti-skid mesh |
|||
| Axle | 13/16/18 ton Multiple brands available | |||
|
Rim |
8.00-20 /8.5-20/8.8-20/8.5-22.5/9.0-22.5Â Â Various models available |
|||
| Manhole cover |
Aluminum alloy |
|||
|
Suspension |
Mechanical suspension or air suspension |
|||
|
Landing Leg |
Standard 28Ton | |||
| King Pin |
2″(50mm)or3.5″(90mm) JOST |
|||
|
Brake System |
Double-line brake system | |||
| Brake Air Chamber |
Aluminum alloy |
|||
| Discharge Valve |
3 or 4 inches in diameter |
|||
| Subsea valve |
Aluminum alloy subsea valve(pneumatic) |
|||
| Electrical System |
24V, 7-core socket, lights according to European standards |
|||
| Lights and Reflectors |
Rear light, rear reflector, turn indicator light, side reflector, fog lamp, number plate light |
|||
| Accessories |
1 box of standard tools, 2 sets of spare tire carriers |
|||
| Painting | Complete chassis sand blasting to clean rust, 1 cost of anticorrosive primer,
2 coats of final paint |
|||
| Color | Customers Optional | |||
