BRIEF
The 6-wheel 6CBM Mobile Gasoline Fuel Truck produced by CSCTRUCK China Tank Truck is a versatile and efficient fuel transportation solution designed for urban and short-distance logistics. Built on a durable FAW chassis with a 4×2 drive configuration, this fuel truck offers reliable performance and ease of maneuverability, making it ideal for narrow city streets or regional delivery routes.
The fuel tank, with a capacity of 6 cubic meters (6CBM), is constructed from high-quality carbon steel, ensuring durability and resistance to wear, corrosion, and leakage. This makes it well-suited for safely transporting various types of fuel.
Powered by a 110HP engine, the truck delivers sufficient power for efficient operation, even when fully loaded. Its engine complies with the EURO 2 emission standard, balancing performance with environmental considerations, although it represents a relatively basic level of emissions compliance compared to modern standards. With a maximum speed of 90 km/h, it provides a balanced combination of speed and fuel efficiency for fuel distribution tasks.
Designed to meet the demands of fuel delivery businesses, this Mobile Gasoline Fuel Truck is a reliable and economical choice for small-scale fuel transportation needs. Its compact size, robust construction, and efficient engine make it an attractive option for operators looking to optimize logistics within urban or semi-urban areas.
FEATURES
- Tank Capacity and Material: Equipped with a 6 cubic meter (CBM) fuel tank made of durable carbon steel, ensuring strength and resistance to corrosion.
- Chassis and Drive Type: Built on a reliable FAW chassis with a 4×2 drive type, providing solid support and efficient performance.
- Engine Performance: Powered by a 110HP engine compliant with EURO 2 emission standards, offering environmentally conscious operations and moderate power output.
- Speed Capability: Designed with a maximum driving speed of 90 km/h, making it suitable for urban and short-haul fuel transport.
- Durability and Design: Features a robust 6-wheeler configuration that ensures stability and a compact design optimized for maneuverability.
SPECIFICATION
General Technical Parameters |
|||
| Overall Dimensions(LxWxH) | 5,990×2,050×2,500(mm) | ||
| Gross Vehicle Weight | 7,360(Kg) | ||
| Curb Weight | 3,760(Kg) | ||
Chassis Specification |
|||
| Chassis Brand | FAW | ||
| Drive model | 4X2 | ||
| Cabin | Single, LHD, with air conditioner | ||
| Number of Passengers | 2 | ||
| Engine | Model | 4-stroke direct injection, 4-cylinder in-line, intercooled supercharging, with ABS. | |
| Power | 81kW/110HP | ||
| Emission standard | EURO 2 | ||
| Fuel type | Diesel | ||
| Gearbox | 5 Forwards & 1 Reverse, manual operation. With power steering. | ||
| Brake System | Oil break | ||
| Wheel Base | 3,300mm | ||
| Front/Rear Axle Loading | 2,000/5,000(Kg) | ||
| Tire | 7.00-16, 6pcs with 1 spare tire | ||
| Max Driving Speed | 90(km/h) | ||
Upper Structure Specification |
||
| Oil Tank | Effective Volume | 6CBM |
| Transport Oil Type | Diesel | |
| Tank dimensions(LxWxH) | 4,000×1,700×1,100mm | |
| Tank Thickness | 4mm | |
| Tank Material | Q235, carbon steel( also can choose stainless steel, aluminum ) | |
| Refueling System | 1. Oil pump;
2. Oil dispenser machine; 3. Hose reel with filling gun. |
|
| Equipment | 1. Manhole 1 Unit
2. Ladder handrail 3. Electrostatic Wire Reel 4. Loading, Discharge 5. Emergency cut-off valve 1 Unit |
|
| Options | Compartments, unloading valve, flow meter, API standard manhole, oil vapor recovery, and anti-overflow probe. | |
