Model No.: | 30 CBM Crude Oil Tank Truck |
Overall Dimensions(LxWxH): | 11,990×2,500×3,540mm |
Chassis Brand: | FAW |
Chassis Model: | CA5310GYYP63K2L6T4E4 |
Drive Type: | 8×4 |
Wheelbase: | 1,950+4,550+1,350mm |
Engine Model: | CA6DL1-32E4 |
Engine Power: | 320HP |
Emission Standard: | Euro 3 |
Tank Volume: | 30,000L |
Tank material: | Carbon steel/Aluminium steel |
Tank dimensions(LxWxH): | 9,100×2,490×1,650mm |
Categories: Aluminum Tank Truck, Carbon Steel Tank Truck, Crude Oil Tank Truck
Description
BRIEF
The 30 CBM crude oil tank truck manufactured by CSCTRUCK China Tank Truck embodies cutting-edge engineering and robust design, tailored to meet the demands of transporting crude oil efficiently and securely. Built on the formidable FAW CA5310GYYP63K2L6T4E4 chassis, renowned for its durability and reliability, this tank truck is equipped with an 8×4 drive-type configuration, ensuring superior traction and stability even in challenging terrains.
At the heart of this powerhouse lies the CA6DL1-32E4 engine model, delivering a formidable 320HP engine power. This engine, compliant with Euro 3 emission standards, not only provides impressive performance but also ensures reduced environmental impact, aligning with modern sustainability goals. Coupled with a 10-speed forward and 2-speed reverse transmission system, this 30 CBM crude oil tank truck offers seamless control and efficiency, enabling smooth navigation through varying road conditions.
With a capacious 30,000L tank volume, this truck boasts ample storage capacity, making it ideal for large-scale crude oil transportation operations. The tank is constructed from durable materials, with a choice between 5mm carbon steel or aluminum steel, ensuring resilience against corrosion and structural integrity even under prolonged use in harsh environments.
Beyond its technical prowess, this 30 CBM crude oil tank truck prioritizes safety and convenience. Equipped with advanced safety features and ergonomic design elements, it offers peace of mind to both drivers and operators. The integration of modern technology enhances operational efficiency, while meticulous attention to detail in design guarantees user comfort and ease of maintenance.
FEATURES
1. Spacious Tank Capacity: With a tank volume of 30,000 liters, this tank truck provides ample space for transporting crude oil efficiently.
2. Sturdy Construction: The tanker is built with high-quality materials, featuring a 5mm carbon steel/aluminum steel construction, ensuring durability and resistance to corrosion, essential for transporting crude oil safely.
3. Powerful Engine: Equipped with a CA6DL1-32E4 engine model boasting 320HP engine power, this tank truck delivers the necessary power and performance to tackle demanding transportation tasks effectively.
4. Advanced Emission Standards: Complying with Euro 3 emission standards, this tank truck ensures reduced emissions, contributing to environmental protection and meeting regulatory requirements.
5. Versatile Transmission: The 10-speed forward 2 reverse transmission system offers versatility in driving, enabling smooth shifting and optimal control, enhancing the overall driving experience and maneuverability, especially in varied terrains.
SPECIFICATION
Vehicle Parameters |
|||
Vehicle Model | 30 CBM Crude Oil Tank Truck | Vehicle brand | CSCTRUCK China Tank Truck |
Vehicle dimension | 11,990×2,500×3,540mm | Curb weight | 13,000kg |
Tank dimension | 9,100×2,490×1,650mm | Tank volume | 30,000L |
Chassis Parameters |
|||
Chassis model | CA5310GYYP63K2L6T4E4 | Chassis brand | FAW |
Overall dimensions | 11,650×2,495×3,454mm | Wheelbase | 1,950+4,550+1,350mm |
Cab | J6P is a row and a row-and-a-half deluxe cab(with sleeping berth), allowable 3 passengers, electric lift glass, ABS, front disc brake, front exhaust pipe, and speed limit device. | ||
Engine | CA6DL1-32E4 | ||
Horsepower | 320HP | ||
Emission Standard | Euro 3 | ||
Displacement | 7,700ml | ||
Tire | 11.00R20 | Transmission | 10 speed forward 2 reverse |
Steering device | Power-assisted steering | Steering wheel | LHD/RHD |
Fuel Tank Parameters |
|||
Tank Volume | 30,000L | Tank dimensions(LxWxH) | 9,100×2,490×1,650mm |
Tank material | Carbon steel/Aluminium steel | Tank thickness | 5mm |
Standard configuration | Chassis, carbon steel/Aluminium steel fuel tank, subframe, oil pump, 2 aluminum alloy flow valves, toolbox, manhole, climbing ladder, fire extinguisher, oil hose. |
