BRIEF
The HOWO 5000L mobile LPG dispenser truck, manufactured by CSCTRUCK China Tank Truck, is designed for flexible LPG distribution in urban and rural areas, small-scale cylinder filling stations, and mobile refueling operations. Its 5,000-liter tank enables safe, efficient transport and dispensing of LPG, making it ideal for door-to-door delivery, temporary fuel depots, and on-site cylinder filling.
Built on a HOWO L2W 2080 chassis, the truck features a left-hand-drive diesel engine (YN4102QBZL) producing 116HP with a 3,760 mL displacement, coupled with a 6-speed forward and 1-speed reverse gearbox (WLY6T46). A wheelbase of 3,360 mm and overall dimensions of 5,900 × 2,400 × 2,650 mm provide compact maneuverability, while a gross vehicle weight of 8,160 kg and payload capacity of 2,310 kg ensure efficient LPG transport. The vehicle rides on 7.50R16 tires (6 + 1 spare) and has a cabin for 2–3 passengers with air conditioning for operator comfort.

The LPG tank, constructed from Q345R steel, has a 10 mm thickness on both tank body and end plates, a diameter of 1,600 mm, and is designed for a working pressure of 1.61 Mpa and test pressure of 2.21 Mpa, ensuring safe operation under high-pressure conditions. The refilling system includes a YQ15-5 pump (15.5 m³/h flow), an LPG dispenser with an English interface and receipt printer, a 15-meter retractable hose, and a nozzle suitable for cylinder filling.
Safety features include a rear-mounted float ball level gauge, DN80 safety valve, 3 emergency shut-off valves, a front-mounted exhaust pipe, and additional accessories such as a thermometer, pressure gauges, and an anti-static line.

In summary, the HOWO 5000L mobile LPG dispenser truck offers robust engineering, operational flexibility, and high safety standards, making it an ideal solution for operators requiring a reliable and versatile LPG distribution vehicle.
FEATURES
- Compact and Maneuverable Design – Built on the HOWO L2W 2080 chassis with a 3,360 mm wheelbase and overall dimensions of 5,900 × 2,400 × 2,650 mm, the truck can navigate urban streets and rural roads efficiently.
- Efficient LPG Transport & Dispensing – Equipped with a 5,000L Q345R steel tank (working pressure 1.61 Mpa, test pressure 2.21 Mpa) and a YQ15-5 pump (15.5 m³/h flow), it safely delivers LPG to cylinder filling stations, temporary depots, or door-to-door customers.
- Advanced Refueling System – Features an LPG dispenser with an English interface and receipt printer, a 15-meter retractable hose, and a cylinder-compatible nozzle, enabling fast and convenient on-site refilling.
- High Safety Standards – Includes DN80 safety valve, 3 emergency shut-off valves, rear float ball level gauge, front exhaust pipe, anti-static line, thermometer, and pressure gauges to ensure secure LPG handling.
- Operator Comfort & Reliability – Powered by a 116HP YN4102QBZL diesel engine with a 6-forward + 1-reverse gearbox, rides on durable 7.50R16 tires (6 + 1 spare), and features a cabin for 2–3 passengers with air conditioning.
SPECIFICATION
| Category | Specification | Parameter / Detail |
| Dimensions & Weight | Overall Dimensions(LxWxH) | 5,900 x 2,400 x 2,650 mm |
| Wheel Base | 3,360 mm | |
| Gross Vehicle Weight | 8,160 kg | |
| Curb Weight | 5,850 kg | |
| Payload | 2,310 kg | |
| Chassis & Engine | Driving Model | Left-hand drive |
| Engine Model | YN4102QBZL, Diesel engine | |
| Engine Horsepower | 116HP EURO III | |
| Displacement | 3,760 mL | |
| Gearbox | WLY6T46, 6-speed forward and 1 reverse | |
| Tire | 7.50R16 (6 pcs + 1 spare) | |
| Cabin | HOWO L2W 2080 (2~3 Passengers, with A/C) | |
| LPG Tank Specs | Volume | 5,000 Liters |
| Tank Material | Q345R | |
| Tank / End Plate Thickness | 10 mm / 10 mm | |
| Tank Dimensions | Diameter: 1,600mm | |
| Design / Testing Pressure | 1.61 Mpa / 2.21 Mpa | |
| Refilling System | LPG Pump | Chinese brand YQ15-5 (Flow: 15.5 M³/H) |
| LPG Dispenser | English remarks with receipt printer | |
| Filling Hose | 15M, retractable | |
| Filling Nozzle | Nozzle for cylinder filling | |
| Safety & Accessories | Level Gauge | Chinese Float Ball type (rear of tank) |
| Safety Valve | 1 unit, DN80 | |
| Emergency Shut-off Valve | 3 pcs (inside valve box and at rear) | |
| Exhaust Pipe | Located at the front of the cabin for safety | |
| Additional Tools | Thermometer (1 pc), Pressure Gauge (2 pcs), Anti-static line. |
