| Model No.: | CSCMFT005 |
| Fuel Tank Volume: | 5,000L |
| Overall Dimensions(LxWxH): | 5,900*2,150*2,400mm |
| Chassis Brand: | FOTON Aumark |
| Drive Type: | 4×2 |
| Wheelbase: | 3,300mm |
| Max. vehicle speed: | 90km/h |
| Engine Power: | 80HP |
| Emission standard: | Euro 3 |
| Fuel Tank Material: | 5mm carbon steel |
BRIEF
The Foton Aumark 5000-liter mobile fuel truck produced by CSCTRUCK China Tank Truck is designed for the transportation and dispensing of fuel, offering efficient and reliable fuel delivery in various commercial and industrial settings. Built on the Foton Aumark chassis, this mobile fuel truck is equipped with a 4×2 drive type, ensuring a balance of maneuverability and stability for urban and rural operations.
With a 5,000-liter capacity fuel tank, it is suitable for medium-scale fueling operations, such as fueling stations, construction sites, and fleet fueling services. The fuel tank itself is crafted from 5mm thick carbon steel, providing strength, durability, and resistance to the wear and tear commonly encountered in fuel transport. It adheres to stringent safety standards, ensuring the secure transport of flammable liquids.
Under the hood, the Foton Aumark 5000L fuel truck is powered by an 80HP engine, delivering adequate power for both city driving and highway transportation. Despite its capacity and engine power, the truck is designed to be efficient, with a maximum speed of 90 km/h, which helps in reducing fuel consumption while maintaining operational flexibility.
The truck meets the Euro 3 emission standard, ensuring a cleaner and more environmentally friendly operation compared to older models. This makes it a suitable choice for regions with stricter environmental regulations.
Overall, the Foton Aumark 5000L mobile fuel truck is a versatile, reliable, and cost-effective solution for transporting and dispensing fuel, combining durability, safety, and efficiency in 1 package. Its robust design and modern engine technology make it ideal for various commercial and industrial applications.
FEATURES
- 5,000L Fuel Tank Capacity: The truck is equipped with a 5,000-liter fuel tank, providing a solid capacity for fuel transport, ideal for medium-scale fueling operations.
- Foton Aumark Chassis: Built on the durable and reliable Foton Aumark chassis, offering a robust foundation for carrying the fuel tank and ensuring stable handling during operations.
- 4×2 Drive Type: The vehicle has a 4×2 drive configuration, making it ideal for urban and short-distance fuel distribution with efficient maneuverability.
- Engine Power & Speed: Powered by an 80HP engine, it is capable of reaching a maximum speed of 90 km/h, providing a balance between performance and efficiency.
- Euro 3 Emission Standard & 5mm Carbon Steel Fuel Tank: Compliant with the Euro 3 emission standard, this fuel truck helps reduce environmental impact while the 5mm thick carbon steel tank ensures durability and resistance to corrosion in harsh fuel transport conditions.
SPECIFICATION
Truck Specification |
|||
| Chassis model | FOTON Aumark | ||
| Cab | Foton single-row cab, with power steering. Electronic flameout, without a/c | ||
| Driving Type | 4*2, Left-hand driving | ||
| Max Speed(km/h) | 90 | ||
| Overall dimension(mm)(LxWxH) | 5,900*2,150*2,400 | ||
| GVW( kg) | 7,500 | ||
| Mass in working order(kg) | 3,500 | ||
| Tank Capacity(L) | 5,000 | ||
| Wheelbase(mm) | 3,300 | ||
| F/R track base (mm) | 1,770/1,640 | ||
| F/R overhang (mm) | 1,230/2,170 | ||
| Approach/Departure Angle | 24/16 | ||
| Tire | 7.50-16 (5+1) | ||
| Clutch | Single-plate dry diaphragm spring clutch | ||
| Steering | Hydraulic steering with power assistance | ||
| Gearbox | 5-speed | ||
| Bridge | Front axle | 2.5T | |
| Rear axle | 5T | ||
| Engine | Model | CY | |
| Fuel Type | Diesel fuel | ||
| Type | Water-cooled four-stroke, direct injection, turbocharged | ||
| Exhaust(ml) | 3,200 | ||
| Max output power/rotate speed (hp/rpm) | 80 | ||
| Max torque/rotate speed(N·m/rpm) | 3,200L | ||
| Braking system | Service Brake | Compressed air brake | |
| Park Brake | Spring energy | ||
| Auxiliary brake | engine exhaust brake | ||
| Electric system | 24v | ||
Upper-Body Specification |
|||
| Volume of tank | 5m3 | ||
| Tank shape | Oval | ||
| Material of tanker | 5mm carbon steel | ||
| Color of the tanker | According to your demands | ||
| Equipment | Oil pump | ||
| Transport medium | Diesel oil, gasoline, or others. | ||
| Tank Mounted on Chassis Brand |
|---|
