BRIEF
The FAW 10-Ton LPG Bobtail Truck is a robust and reliable solution designed for the safe and efficient transportation of LPG (Liquid Petroleum Gas). This versatile vehicle is meticulously assembled, combining a FAW truck chassis, an LPG tank, an LPG vane pump, and a PLG filling system that includes crucial instruments such as a flow meter, a temperature meter, a 15-meter filling hose, and a filling gun. The LPG tank is specifically engineered for transporting LPG in its liquid gas state, particularly when it consists of a butane and propane mixture, with the weight of propane capped at a maximum of 30%.
FEATURES
- Chassis and Performance
- Fitted with a rugged FAW truck chassis, featuring a 340hp engine.
- Meets Euro 2 emission standards, reducing environmental impact.
- Equipped with a 9-speed manual transmission (9 front gears and 1 reverse).
- Tire specifications: 11.00R20, including 10 regular tires and 1 spare tire.
- Vane Pump
- Features the trusted USA Corken vane pump, specifically the Z2000 model, ensuring efficient and secure LPG transfer.
- LPG Tank
- The 10-ton LPG tank has a generous capacity of 22,000 liters and is constructed from robust Q345R material with a 10mm thickness.
- Designed to handle a substantial loading capacity of 10 tons, making it suitable for various LPG transportation requirements.
- Instrumentation
- Standard instruments include a pressure meter, a temperature meter, and a liquid gauge, providing precise monitoring and control.
- Optional Electronic Scale
- For enhanced precision and accuracy in LPG measurements, an electronic scale is available as an optional feature.
SPECIFICATIONS
| Chassis | |
|---|---|
| Size | 10,500 x 2,480 x 3,420 (mm) |
| GVW/Curb Weight | 25,000/14,240 kg |
| Wheelbase | 4,615 + 1,350 mm |
| Tire | 11.00R20, 10 regular tires + 1 spare tire |
| Engine | |
| Type | Diesel |
| Make/Model | WEICHAI/WP10.340E22 / 340hp / Euro 2 |
| Transmission | |
| Model | SHANXXI FAST/9JSD135T |
| Gears | 9F + 1R |
| Operation | Manual |
| Cabin | |
| Driving | FAW, 6×4, LHD / RHD |
| Type | Seats, radio, MP3 |
| Passenger No. | 2 seats & 1 sleeper |
| LPG TANK | |
| Filling Medium | LPG |
| Capacity | 10 tons / 22,000 Liters |
| Working Temperature | -40 ~ 50°C |
| Tank Material | Q345 |
| Tank Diameter | 2,050 mm |
| Tank Thickness | 12 mm |
| End Plate Thickness | 12 mm |
| Tank Length | 8,060 mm |
| Gas Phase | Flange Type, DN50, other sizes optional |
| Liquid Phase | Flange Type, DN80, other sizes optional |
| Working Pressure | 1.61 Mpa |
| Design Pressure | 1.71 Mpa |
| Testing Pressure | 2.21 Mpa |
| Corrosion Allowances | 1.0 mm |
