| Model No.: | CSCWTST040 |
| Tank Capacity: | 40,000L |
| Overall Dimensions(LxWxH): | 13,000×2,500×3,500mm |
| Axle: | 3x13T capacity, FUWA/BPW |
| Suspension: | Spring mechanical suspension or air suspension |
| Leaf spring: | Leaf spring or air bag |
| Manhole cover: | 500mm manhole cover |
| Discharge valve: | 2-4 sets of φ100mm discharge valve |
| Discharge pipe: | 4″ rubber hose, 2 pcs, 6m long |
| Kingpin: | 50#/90# bolt-in kingpin |
| Landing gear: | JOST brand 2-speed, manual operating |
BRIEF
The 40,000-liter water tanker semi-trailer manufactured by CSCTRUCK China Tank Truck is a high-capacity liquid transport solution designed for efficient and reliable water delivery. This semi-trailer features a 40,000-liter tank capacity, making it ideal for industrial, municipal, and agricultural water transport applications.
Built with durability in mind, the water tanker semi-trailer is equipped with a 3x13T axle system using FUWA or BPW axles, ensuring excellent load-bearing capacity and road stability. The suspension system is available in either spring mechanical suspension or air suspension, providing flexibility for different operational needs. The trailer also offers leaf spring or air bag suspension options, enhancing shock absorption and ride quality.
For ease of access and maintenance, the tanker includes a 500mm manhole cover, allowing safe entry for inspection and cleaning. The discharge system consists of 2-4 sets of φ100mm discharge valves, enabling efficient unloading of water. The tanker is also equipped with two 4-inch rubber hoses, each 6 meters long, facilitating smooth and quick water discharge.
The coupling system features a 50#/90# bolt-in kingpin, ensuring a strong connection between the semi-trailer and the towing truck. The JOST brand 2-speed manual operating landing gear provides stable and secure parking support.
Overall, the 40,000L water tanker semi-trailer is a robust and high-performance transport solution, engineered to meet the demands of heavy-duty water transportation with reliability and efficiency.
FEATURES
- High-Capacity Tank – The tanker has a 40,000L capacity, designed for efficient bulk water transportation.
- Robust Axles & Suspension – Equipped with 3x13T axles (FUWA/BPW brand) and offers spring mechanical or air suspension, with options for leaf spring or airbag suspension for better stability.
- Efficient Discharge System – Features a 500mm manhole cover and 2-4 discharge valves (φ100mm), along with two 6-meter-long 4” rubber hoses for smooth water discharge.
- Strong Coupling & Support System – Utilizes a 50#/90# bolt-in kingpin for secure attachment and JOST brand 2-speed manual operating landing gear for stable parking and easy maneuverability.
- Durable Construction – Built with high-quality materials, ensuring reliability in heavy-duty operations, making it ideal for industrial, agricultural, and emergency water supply applications.
SPECIFICATION
Specification of Water Tanker Semi Trailer |
||||
|
Overall Size(LxWxH)
|
13,000×2,500×3,500mm
|
|||
|
Tank capacity
|
40,000L
|
|||
|
Tank body
|
Aluminum alloy material/5.5mm steel
|
|||
|
End plate
|
Aluminum alloy material/6mm steel sheet
|
|||
|
Axle
|
3*13T capacity, FUWA / BPW or other brand
|
|||
|
Suspension
|
Spring mechanical suspension or air suspension
|
|||
|
Leaf spring
|
Leaf spring or air bag
|
|||
|
Manhole cover
|
500mm manhole cover
|
|||
|
Discharge valve
|
2-4 sets of φ100mm discharge valve
|
|||
|
Discharge pipe
|
4″ rubber hose, 2 pcs, 6m long
|
|||
|
Bottom valve
|
1- 2 sets of bottom valve
|
|||
|
Outside sheet
|
1.2mm steel sheet
|
|||
|
Compartment
|
Optional upon choice
|
|||
|
Tire
|
11.00R20, 12.00R20, 11R22.5, 12R22.5, 315/80R22.5 Tire optional
|
|||
|
Wheel rim
|
8.5-20, 9.0-20, 8.25-22.5, 9.0-22.5 steel wheel rim optional upon choice
|
|||
|
Kingpin
|
50# / 90# bolt-in kingpin
|
|||
|
Landing gear
|
JOST brand 2-speed, manual operating, heavy duty landing gear
|
|||
|
Braking system
|
Dual line brake system; T30/30 spring brake chamber; 40L air tanks
|
|||
|
Painting
|
Complete chassis sand blasting to clean rust, 1 coat of anti-corrosive prime, 2 coats of final paint
|
|||
|
Accessories
|
1 standard tool box.
|
|||
| Tank Mounted on Chassis Brand |
|---|
