Model No.: | 25 CBM 6×6 Off Road Fuel Tank Truck |
Fuel Tank Volume: | 25 CBM |
Overall Dimensions(LxWxH): | 7,760×2,500×3,150mm |
Chassis Brand: | Dongfeng |
Drive Type: | 6×6 |
Wheelbase: | 3,475+1,250(mm) |
Engine Model: | Cummins EQ6BT5.9 |
Engine Power: | 250HP |
Emission Standard: | EURO 5 |
Maximum Speed: | 95km/h |
Fuel Tank Material: | Carbon Steel |
Thickness of tank body: | 5mm |
Maximum Wading Depth: | 1m |
Categories: Carbon Steel Tank Truck, Fuel Tank Truck
Description
BRIEF
The 25 CBM 6×6 off-road fuel tank truck, produced by CSCTRUCK China Tank Truck, is a robust and versatile vehicle designed for challenging terrains and demanding fuel transport requirements. Built on the reliable Dongfeng chassis, this truck features a 6×6 drive type, ensuring excellent traction and stability in off-road conditions. The vehicle is equipped with a Cummins EQ6BT5.9 engine, delivering 250 horsepower, which meets the EURO 5 emission standard, making it both powerful and environmentally friendly.
The fuel tank has a capacity of 25 cubic meters, constructed from durable carbon steel with a 5mm thickness, providing resilience against wear and tear. This construction ensures the safe transport of fuel, reducing the risk of leaks or ruptures. The fuel tank truck can achieve a maximum driving speed of 95 km/h, allowing for efficient fuel delivery over long distances. Its off-road capabilities are further enhanced by a maximum wading depth of 1 meter, enabling it to navigate through waterlogged areas without compromising performance.
This model combines high performance with environmental compliance, making it suitable for various industries requiring reliable fuel transportation in rugged environments. The 25 CBM fuel tank truck is a testament to advanced engineering and practical design, providing a valuable asset for operations in remote and challenging locations. Its combination of power, capacity, and durability ensures it meets the rigorous demands of off-road fuel transport, while the compliance with EURO 5 standards underscores its commitment to reducing environmental impact.
FEATURES
1. Off-Road Capabilities:
  – The truck features a 6×6 drive type, providing superior traction and stability on challenging terrains, making it ideal for off-road conditions.
2. Powerful Engine:
  – Equipped with a Cummins EQ6BT5.9 engine model, the truck boasts 250HP engine power, ensuring robust performance for heavy-duty tasks.
3. Large Fuel Tank Capacity:
  – The truck comes with a substantial 25 CBM fuel tank, which allows for the transportation of large volumes of fuel, enhancing efficiency in fuel delivery operations.
4. High Emission Standards:
  – Adhering to the EURO 5 emission standard, the truck ensures lower emissions, contributing to reduced environmental impact and compliance with stringent emission regulations.
5. Durable Construction:
  – The fuel tank is made of carbon steel with a thickness of 5mm, providing durability and resistance to wear and tear. Additionally, the truck can wade through water up to a maximum depth of 1 meter, showcasing its versatility and resilience in various conditions.
SPECIFICATION
25 CBM 6×6 Off Road Fuel Tank Truck |
|
Chassis Brand | Dongfeng |
Drive Type | 6×6 |
Engine | Cummins EQ6BT5.9 |
Cabin | Row and half |
Transmission | 6 forwards & 1 reverse |
Axle Load | 3.7tons/2x4tons |
Clutch | Hydraulically operating with air assistance |
Rim/Â Tire | 12.50R20, Radial tyre |
Wheelbase | 3,475+1,250(mm) |
Capacity of tank body | 25m3 |
Thickness of tank body | 5mm |
Overall dimensions(LxWxH) | 7,760×2,500×3,150mm |
The curb weight | 7,120(kg) |
Gross weight | 10,940kg |
Max. speed | 95km/h |
Maximum climbing grade | 60% |
Vertical obstacle height | 700mm |
Maximum wading depth | 1m |
Color | White, red, green, golden, and so on. |
