This Dongfeng Huashen DV3 14000-liter fuel tanker truck adopts the Dongfeng Huashen DV3 semi-high-roof cab. The headlights on both sides of the cab are of the latest design, with a new-style fog light on each side of the front bumper. The front grille panel features 2 prominently curved wind vents separated by an aluminum alloy strip in the middle, giving it a dynamic and youthful appearance with an understated sense of luxury and refinement.
The cab comes standard with air suspension seats, remote key, air conditioning, power windows, cruise control, Bluetooth phone, and electrically adjustable and heated rearview mirrors, offering a high level of comfort.
Specification |
Details |
|---|---|
| Emission Standard | EURO VI |
| Engine | Yuchai 4-cylinder, 200 horsepower |
| Transmission | Fast 8-speed |
| Wheelbase | 4.2 meters |
| Front Axle | 3.7-ton disc axle |
| Rear Axle | Dongfeng-Dana 9-ton air suspension axle |
| Tires | 275/80R22.5 18PR tubeless |
| Fuel Tank | Aluminum alloy |
| Special Feature | Lightweight design, qualifies as a hazardous materials chassis |
Item |
Specification |
|---|---|
| Overall Dimensions | |
| Length | 7.65 meters |
| Width | 2.5 meters |
| Height | 3.1 meters |
| Weights | |
| Gross Vehicle Weight | 18 tons |
| Curb Weight | 7.205 tons |
| Rated Payload | 10.6 tons |
| Tank Body | |
| Shape | Rounded-rectangular |
| Tank Length | 5.1 meters |
| Tank Width (Long Axis) | 2.2 meters |
| Tank Height (Short Axis) | 1.45 meters |
| Tank Volume | 13.4 m³ |
| Max Approved Medium Density | 830 kg/m³ |
| Protection Structures | |
| Material | Q235 Steel |
| Connection Method | Bolted and Welded |
| Rear Protection Dimensions | 120 × 60 mm |
| Rear Ground Clearance | 450 mm |
The tank is rated to carry 10 tons of diesel and comes standard with a single-compartment design with a pump. It is equipped with a full set of European-standard bottom-loading fuel system components, including:
- One bottom-loading/unloading valve
- One oil vapor recovery valve
- One vapor recovery port
- One anti-overflow probe
- One five-pin socket
- One European-standard manhole cover
- One emergency shut-off valve
- A smart voice alarm system
This Dongfeng Huashen DV3 14000-liter EURO VI-compliant fuel tanker truck offers strong climbing performance and high torque. It uses air brake (spring brake chamber) technology, ensuring strong safety performance.
