This Dongfeng Chenglong H5 Triple-Axle 21 CBM aluminum fuel tanker truck is equipped with the Liuzhou Motor Chenglong H5 extended cab with a sleeper. It features a Yuchai 240-horsepower engine, compliant with EURO V emission standards, and a 6-cylinder engine. It is paired with a Fast 8-speed manual transmission. The front axle is a dual 5.5-ton setup, with a 280 mm chassis and a wheelbase of 1,950+5,450 mm. The vehicle is fitted with 11.00R20 steel radial tires and comes with a 350-liter aluminum alloy fuel tank, which is lightweight and highly corrosion-resistant.
The cab is mounted on a mechanical full-floating suspension and includes manual hydraulic tilting. Standard features include a mechanical shock-absorbing seat, electric power windows, remote central locking, air conditioning, a driving recorder, compatibility with Beidou GPS, and a sun visor.
The chassis also comes standard with exhaust brake, domestic valves, ABS (WABCO), automatic slack adjusters, an electromagnetic clutch fan, main power switch, front-mounted exhaust pipe, exhaust spark arrestor, front disc brakes, ECU speed limiter (speed limit: 80 km/h), an in-cab master power switch, and color-matched bumper and fenders.
The upper-mounted tank is made of aluminum alloy with an effective volume of 20.5 cubic meters and a thickness of 6 mm. Standard configuration includes a full European standard set: 2 European standard manholes, 1 bottom valve, 1 bottom loading port, 1 vapor recovery system, 1 anti-overflow probe, and a socket. The bottom loading and pump-in/pump-out system is located on the co-driver’s side. An AOKE brand automatic bottom valve shut-off system is added, along with a static grounding reel.
On the driver’s side, there is a dual-door toolbox matching the Dongfeng Chenglong H5 Triple-Axle 21 CBM aluminum fuel tanker truck announcement photo, with a foldable guardrail. The rest is built according to aluminum tank standards. Additional equipment includes 1 flame arrester cap, 2 oil delivery hoses (each the same length as the tank), and 2 fire extinguishers. All other configurations are standard.
